Induction Heating Bolt machine :

Induction bolt heating involves heating drilled stud bolts to obtain elongation. Thus, it only takes a few minutes to heat them evenly and safely. This process is 2 to 3 times faster than conventional heating means such as heating rods
A proven method
In 2018we launched our first machines and our first interventions. Since then, we have traveled across Europe and even the world: Japan, China, USA, Mexico, Turkey, UK, France…

Our main induction tightening operations are carried out on turbines (hydraulic, steam, gas) and compressors of all sizes.

The advantages of our induction bolt heating service

Easy to set up and use: all you need is a 380 -480 volts 32A outlet
Light & compact design,
Can connect industrail chiller Cooling system with machine
Timer integrated to control heating time
User-friendly, easy to operate with automatic or manual power regulation
3-80meters length of coaxial cable to access both sides of the turbine
No exceeding of the Curie point (no material transformation)
No burning risk as inductor remains cold
All sizes inductors manufacturing, in 72 hours on demand
Only heat the center of the bolt, for accurate tightening and to minimize heat dispersion
Quick heating time

The techincal parameters of induction heating bolt machine :

​

Type	DSP-80KW
Rated Output Power	80KW
Rated Output Frequency	10-40KHZ
Can expand frquency	1-100khz
Overload Heating time	45%/10min
Power Adjust Arrange	1.5-100%
Coaxial Flexible cable length	5M,6M...10M,20M,30M,40M,50M
Input Voltage	360-420v 50-60hz
Max power	80kw
Protection Level	IP54
Environment Temperature	+5c--+50C
Cooling water flow	31L/MIN
Cooling water Pressure	4-8Bar
Weight	About 180kg

​Induction heating machine applications:
