80kHz-150kHz Frequency Vertical Type Induction Heating Machine with 6000/Month Production Capacity for Metal-Processing Industry

Large Image : 80kHz-150kHz Frequency Vertical Type Induction Heating Machine with 6000/Month Production Capacity for Metal-Processing Industry

Product Details:

Certification:	CE, RoHS, SGS

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	6500

Contact Now

80kHz-150kHz Frequency Vertical Type Induction Heating Machine with 6000/Month Production Capacity for Metal-Processing Industry

Description

Model NO.:	UHF-80KW	Type:	Induction Heating Machine
Structure:	Vertical Type	Power:	80kw
Frequency:	80kHz-150kHz	Cooling System:	Water Cooling System
Core Components:	IGBT	Induction Coil:	Based On The Customer's Workpiece
Max Current:	120A	Machine Size:	680MM620MM1100MM
Production Capacity:	6000/Month	Frequency Range:	80-500KHZ
Test Video:	Provided	Transport Package:	Export Wooden Box Packaging
Heating Method:	Non-contact Electromagnetic Induction
Highlight:	80kHz-150kHz Frequency Induction Heating Machine , 6000/Month Production Capacity High Frequency Induction Heater , Vertical Type Induction Heater

Induction Heating Machine for Heat Treatment Metals in Metal-Processing Industry (UHF-80KW)

This induction heating machine provides a fast, efficient, precise, and repeatable non-contact method for heating metals and other electrically-conductive materials. The system includes an induction power supply that converts line power to alternating current, delivering it to a workhead and work coil to create an electromagnetic field. The workpiece placed in this coil experiences induced current, generating heat efficiently.

Key Applications

Induction Heat Treatment

Surface Hardening (Quenching): Rapidly heats metal surfaces followed by immediate cooling to create a hard, wear-resistant outer layer while maintaining a tough, ductile core. Ideal for gears, shafts, crankshafts, and various tools.
Annealing and Tempering: Annealing softens metals to improve machinability or relieve internal stresses, while tempering reduces brittleness after hardening. Allows precise local annealing of parts like stainless steel strips or specific component sections.

Heating for Forming

Hot Forging and Forming: Heats metal billets or workpieces to plastic temperatures for shaping into tools, automotive parts, and fasteners using presses or hammers.
Hot Fitting: Heats metal parts (like bearings) for expansion during assembly. Upon cooling, creates a tight interference fit.

Welding, Brazing, and Soldering

Brazing and Soldering: Melts filler metal to create strong joints between close-fitting parts, commonly used in plumbing, electrical work, and automotive manufacturing.
Shrink Fitting: Uses heat to assemble or disassemble tightly fitted parts like bearings, gears, and railway wheels.

Metal Melting

Smelting and Foundry: Efficiently melts iron, steel, copper, aluminum, and precious metals with minimal melt loss and precise temperature control.

Specialized Applications

Induction Sealing: Hermetically seals containers in food and pharmaceutical industries by heating aluminum foil liners.
Plastic Processing: Heats plastic injection molding machine barrels directly, reducing warm-up times and energy consumption.

Technical Specifications

Model	UHF-80KW
Power	80KW
Max Current	120A
Frequency	80-500KHZ
Test Video	Provided
Cooling System	Water Cooling System
Machine Size	680MM620MM1100MM

After Sales Service

Warranty: 18 months from delivery date or 12 months from receiving date.
Parts Replacement: All parts are free within warranty for non-artificial faults.
Maintenance Service: For major quality issues beyond warranty, we provide visiting service at favorable prices.
Lifetime Support: Lifetime cost price for materials and spare parts used in system operation and maintenance.

Company Profile

OURUIDA CO.,LTD (Foshan Sinfor Electro-Mechanical Equipment Co.,LTD) was established in Foshan in 2000. We specialize in researching, developing, manufacturing, and marketing high-quality induction heating machines, melting furnaces, air-cooled water chillers, induction hardening machine tools, and PLC/CNC machine tools with fast shipping and excellent after-sales service.

Frequently Asked Questions

How to choose power (kW) and frequency (kHz) for different workpieces?

Please provide processing drawings or workpiece dimensions and heating areas. Based on these details and your process requirements, we will recommend the optimal power (kW) and frequency (kHz) configuration.

How to ensure uniform hardening depth and avoid cracks?

Depth Control: Adjust frequency (80% impact), heating time, and preheating. Use IR pyrometers (±2°C accuracy) for real-time temperature monitoring.

Why choose our factory equipment?

We have 25 years of manufacturing experience and the capability to solve all technical challenges related to induction heating applications.
