30-80kHz High Frequency Induction Heating Machine with 220V/380V and 400V for Steel Wires Annealing

Large Image : 30-80kHz High Frequency Induction Heating Machine with 220V/380V and 400V for Steel Wires Annealing

Product Details: Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	2200

Contact Now

30-80kHz High Frequency Induction Heating Machine with 220V/380V and 400V for Steel Wires Annealing

Description

Model NO.:	DSP-15KW	Principle:	Non-Contact Heating
Power:	15kw	Input Current:	25A
Frequency:	30-80kHz	Work Voltage:	220V/380V, 400V, 415V, 440V, 480V*3phase
Water Temperature Protection:	40c	Structure Material:	Metal Material
Water Pressure:	0.1-0.3MPa	Cooling System:	Water Cooling System
Control Circuit:	Digital Infineon IGBT	Operate Interface:	Touch Screen
Remote Communication:	Rs485 Communication Interface	Power Adjustment:	5% To 100%
Heating Efficiency:	High
Highlight:	30-80kHz Induction Heating Equipment , 220V/380V High Frequency Induction Heating Machine , 400V IGBT Induction Heater

DSP-15KW Full Digital High Frequency Induction Heating Machine for Steel Wires Annealing

Key Features

Utilizes digital signal processing (DSP) and direct digital frequency synthesizer (DDS) technology with Infineon IGBT components
Advanced digital control technology with digital phase-locked loop tracking and computer control for reliable, stable operation
Imported integrated circuits and power modules enable automatic frequency tracking
Compact design with high efficiency, energy savings, and simple installation
Fast heating speeds with precise temperature and time control for consistent quality
Visual digital display of voltage, current, frequency, power, heating time, and temperature
Predictable power setting capability before heating begins
Multiple interface options including LED indicators, digital tube displays, and touch screens
Hardware isolation interface compatible with existing PLC systems
RS485 communication interface for remote connectivity
Emergency stop button for immediate equipment shutdown
Optimized internal component layout to minimize interference
Remote control capability with power adjustment from 5% to 100% resolution

Advantages Over SCR Parallel Induction Heating Machines

20-30% energy savings compared to SCR parallel type machines
Series Resonance IGBT design prevents interference with other equipment
No special input transformer required
Easy operation without main board or capacitor adjustments
Pre-configured for immediate use after factory debugging
Touch screen display for real-time monitoring of frequency, power, and current
Enhanced stability with integrated water pressure and temperature monitoring

Applications

This high-frequency induction heating machine is suitable for various industrial processes including:

Hardening: Gear, shaft, pipe, bearing, pump fitting, steel plate, roller
Forging: Bar, flat plate, bar end heating, pipe ends
Pre-heating: Pipe, steel wire, stainless steel wire
Brazing: Saw blades, carbide tools, copper tube, aluminum parts, drilling tools
Annealing: Steel pipe, golf ball head, brass lock, aluminum pan
Shrink fitting: Motor, pipe
Melting: Iron, steel, brass, aluminum, silver, zinc
