CE Certificated Vertical Type High Frequency Induction Heater with Infineon IGBT for Efficient Heating and Quenching

Brand Name: OURUIDA
Model Number: SF-40KW
MOQ: 1
Price: 3000
Packaging Details: Export Wooden box Packaging
Payment Terms: Western Union,T/T,L/C,D/A,MoneyGram
Detail Information
Product Description
Detail Information
Place of Origin:
CHINA
Certification:
CE, ISO
Model NO.:
HF-60KW
Type:
Induction Heating Machine
Structure:
Vertical Type
Actual Power:
40kw
Working Frequency:
30-80kHz
Work Voltage:
380V, 400V, 415V,440V, 480V,220V*3phase 50-60Hz
Input Current:
60A
Fluctuating Power:
60kw
Output Power:
60Kw
Fluctuating Frequency:
30-80khz
Cooling Water Flow:
0.15 Mpa 11L/Min
Water Temperature Protection:
40centidegree
Duty Cycle:
100% (40degree Room Temperature)
Weight:
Mainparts:55Kg Transformer:51kg
Size:
Main Parts:640*280*550MM Transformer: 510*260*410MM
Supply Ability:
1000SETS /Month
Highlight:

CE Certificated Induction Heater

,

Vertical Type Induction Heating Machine

,

Infineon IGBT Induction Heater

Product Description
60A CE Certificated High Frequency Induction Hardening Machine
The 60A High Frequency Induction Hardening Machine is a versatile induction heating equipment designed for hardening, quenching, soldering, and welding applications. Featuring advanced technology and safety features, this machine delivers efficient, precise heating for industrial metal processing.
Key Features
  • Non-contact heating technology for precise temperature control
  • Compact and lightweight design for easy operation
  • High-frequency, rapid heating capability (30-80kHz)
  • Automated temperature control ensures consistent product quality
  • Safety voltage output (below 36V) with isolation transformer
  • Infineon IGBT module and third-generation inverting technology
  • 100% duty cycle allows continuous operation at maximum power
  • 20-30% energy savings compared to SCR machines
  • Comprehensive protection system (overheat, overcurrent, voltage monitoring)
  • Programmable timer for batch production repeatability
CE Certificated Vertical Type High Frequency Induction Heater with Infineon IGBT for Efficient Heating and Quenching 0
CE Certificated Vertical Type High Frequency Induction Heater with Infineon IGBT for Efficient Heating and Quenching 1
Technical Specifications
Type HF-60KW
Work Power 3*220V/380v/415v/440v/480v 50-60hz
Operating Voltage Range 340-430V AC
Output Power 60Kw
Input Current 60A
Frequency Range 30-80kHz
Timing Control 1-99S (Heat time, Retain time, Cool time)
Cooling Water Flow Rate 0.15 Mpa 11L/Min
Water Temperature Protection 40°C
Duty Cycle 100% (at 40°C room temperature)
Weight Main parts: 55Kg, Transformer: 51kg
Dimensions Main Parts: 640*280*550MM, Transformer: 510*260*410MM
Applications
  • Heat treatment for various metals (shafts, gears, pipes)
  • Soldering copper and brass components
  • Annealing stainless steel, copper, and aluminum
  • Hot forging for copper, brass, and steel components
  • Melting precious metals (gold, silver, platinum)
  • Processing various metals including stainless steel, iron, aluminum
CE Certificated Vertical Type High Frequency Induction Heater with Infineon IGBT for Efficient Heating and Quenching 2
CE Certificated Vertical Type High Frequency Induction Heater with Infineon IGBT for Efficient Heating and Quenching 3
CE Certificated Vertical Type High Frequency Induction Heater with Infineon IGBT for Efficient Heating and Quenching 4
Product Advantages
  • Fast delivery with available stock (1-2 days shipping)
  • 23 years of manufacturing experience with CE certification
  • Significant energy savings (20-30% vs SCR machines)
  • 24/7 customer support for technical assistance
  • Premium Infineon IGBT components
  • Comprehensive warranty coverage
  • Dual transformer ratios for flexible coil connections
CE Certificated Vertical Type High Frequency Induction Heater with Infineon IGBT for Efficient Heating and Quenching 5
CE Certificated Vertical Type High Frequency Induction Heater with Infineon IGBT for Efficient Heating and Quenching 6
CE Certificated Vertical Type High Frequency Induction Heater with Infineon IGBT for Efficient Heating and Quenching 7
CE Certificated Vertical Type High Frequency Induction Heater with Infineon IGBT for Efficient Heating and Quenching 8
CE Certificated Vertical Type High Frequency Induction Heater with Infineon IGBT for Efficient Heating and Quenching 9
CE Certificated Vertical Type High Frequency Induction Heater with Infineon IGBT for Efficient Heating and Quenching 10
CE Certificated Vertical Type High Frequency Induction Heater with Infineon IGBT for Efficient Heating and Quenching 11
