IGBT Induction Heating Machine High Frequency Induction Heater with 3*380V/415V/440V/480V 340-430V AC and 1-99s Timing

MOQ: 1
Price: 1
Detail Information
Product Description
Detail Information
Certification:
CE, ISO, RoHS
Model NO.:
HF-25KW
Type:
Induction Heating Machine
Structure:
Vertical Type
Power:
25kw
Frequency:
30-80kHz
Work Power:
3*380V/415V/440V/480V 50-60Hz
Operating Voltage:
340-430V AC
Input Current:
25A
Timing Range:
1-99s
Water Temperature Protection:
40centidegree
Weight:
42kg
Size:
640*280*550mm
Output Power:
25KW
Cooling Water Flow:
0.15 Mpa 9L/Min
Duty Cycle:
100% (40degree Room Temperature)
Highlight:

3*380V/415V/440V/480V IGBT Induction Heating Machine

,

340-430V AC High Frequency Induction Heater

,

1-99s Timing Induction Heating Equipment

Product Description
IGBT Induction Heating Machine for Tubes, Bars and Metal Fittings
Premium Industrial Heating Solution
Our high-performance IGBT induction heating machine provides efficient heating for various metal components including tubes, bars, and fittings. Manufactured in China with competitive pricing, this equipment delivers reliable performance for industrial applications.
IGBT Induction Heating Machine High Frequency Induction Heater with 3*380V/415V/440V/480V 340-430V AC and 1-99s Timing 0 IGBT Induction Heating Machine High Frequency Induction Heater with 3*380V/415V/440V/480V 340-430V AC and 1-99s Timing 1 IGBT Induction Heating Machine High Frequency Induction Heater with 3*380V/415V/440V/480V 340-430V AC and 1-99s Timing 2 IGBT Induction Heating Machine High Frequency Induction Heater with 3*380V/415V/440V/480V 340-430V AC and 1-99s Timing 3
Key Advantages
  • Over ten years of manufacturing experience ensures stable performance
  • CE certified for quality assurance
  • Trusted by major brands including CHOW TAI FOOKS, Matsushita, Foxconn, Media, Gree, and ZHIGAO Air conditioner
  • Versatile applications: heating, quenching, forging, melting, and soldering
Technical Specifications
Model HF-25AB/25A
Work Power 3*380v/415v/440v/480v 50-60hz
Operating Voltage Range 340-430V AC
Output Power 25KW
Input Current 25A
Fluctuating Frequency 30-80khz
Timing (Heat/Retain/Cool) 1-99S
Cooling Water Flow Rate 0.15 Mpa 9L/Min
Water Temperature Protection 40°C
Duty Cycle 100% (40°C room temperature)
Weight Main parts: 42Kg
Dimensions Main Parts: 640*280*550mm
IGBT Induction Heating Machine High Frequency Induction Heater with 3*380V/415V/440V/480V 340-430V AC and 1-99s Timing 4 IGBT Induction Heating Machine High Frequency Induction Heater with 3*380V/415V/440V/480V 340-430V AC and 1-99s Timing 5 IGBT Induction Heating Machine High Frequency Induction Heater with 3*380V/415V/440V/480V 340-430V AC and 1-99s Timing 6
Comprehensive Service Support
Pre-Sale Services
  • Customized machine recommendations based on requirements
  • Expert consultation and inquiry support
  • Sample testing assistance
  • Factory visit arrangements
In-Sale Services
  • Manufacturing according to strict technical standards
  • Comprehensive equipment testing
  • Thorough quality inspection before delivery
  • Guaranteed on-time delivery
After-Sale Services
  • 18-month warranty from delivery date or 12-month from receipt
  • Free replacement of all non-artificial defect parts during warranty
  • Technical support for major post-warranty issues at favorable rates
  • Lifetime cost-price supply of spare parts and materials
  • Additional quality and operation guarantees beyond basic requirements
