Name: Most Energy Conservation Induction Heating Equipment for Welding, Smelting, Heat Treament
Brand: OURUIDA CO.,LTD
Price: 600 USD
Availability: InStock

Brand Name:	OURUIDA
MOQ:	1
Price:	600

Detail Information

Product Description

Detail Information

Place of Origin:

CHINA

Certification:

SGS/ROHS/CE

Model NO.:

HF-15A

Structure:

Vertical Type

Brand:

Ouruida

Power:

15kw

Frequency:

30-100kHz

Input Current:

36A

Input Voltage:

220V,240V Simple Phase/ 380V*3phase

Transport Package:

Wooden Box

Specification:

CE, SGS, ISO

Trademark:

ORD

Origin:

China

HS Code:

8514400090

Production Capacity:

10, 000sets

Highlight:

energy efficient induction welding equipment

high frequency smelting induction heater

induction heating equipment for heat treatment

Product Description

Induction Heating Machine:

Advantage:

IGBT
DELIXI Air Switch
Phase Bridge ( Germany IXYS)
Filter Capacitor (Janpan chemi-con)
All screws are Stainless Steel
More than 19 year experience, rich experience, stable performance, good quality.
Copperated with CHOW TAI FOOKS, Matsushita, Foxconn, Media, Gree and ZHIGAO Air conditioner
Suitable for a large range, heating, quenching, forging, melting, solding and so on.

Main characteristics:

IGBT module and Inverting technologies of third generation been used; Higher reliability and lower maintenance cost.
100% Duty cycle, continuous working is allowed at maximum power output.
Display of heating power and heating current and oscillating frequency;
Simple to install, Installation can be done by unprofessional person very easily;
Light weight
Advantages of the model with timer: The power and the operating time of the heating period and the retain period can be preset respectively, to realize a simple heating curve, this model is suggested to use for batch production to improve the repeatability;

Applications:

Drill tip heat shaping
Heat treatment
Quenching
Forging
Melting
Soldering and brazing
Welding

Type	HF-15AB/15A
Work Power	single phase 220v 50-60hz
The range of operating voltage	180-250V AC
Output power	15KW
Input current	36A
Fluctuating frequency	30-100khz
Timing (Heat time,Retain time,Cool time)	1-99S
The flow rate of cooling water	0.15 Mpa 7.6L/Min
Water temperature protection point	40centidegree
Duty cycle	100% (40degree room temperature)
Weight	Mainparts:35Kg
Size	Main Parts:640280550mm
