Good price online

products details

Home > Products >
High Frequency Induction Heater
>
IGBT portable Handheld High Frequency Induction Heater Hf-40kw
All Category

Industrial Induction Heating Machine

Portable Induction Heating Machine

Induction Heating Equipment

High Frequency Induction Heater

Medium Frequency Induction Heating Machine

Ultra High Frequency Induction Heating Machine

Induction Hardening Machine

Induction Melting Furnace

Induction Quenching Machine

Induction Forging Furnace

Induction Forging Machine

PWHT Machine

Induction Annealing Equipment

Induction Brazing Machine

Induction Soldering Machine

Induction Heat Treatment Equipment

Air Cooled Water Chiller

Infrared Thermometer
Contact Us
Ms. Joanna Bao
Joannabao@ordheater.com
+8613549425605
wechat Joanna8608
Contact Now
IGBT portable Handheld High Frequency Induction Heater Hf-40kw
  • name
  • name
  • name
  • name
  • name

IGBT portable Handheld High Frequency Induction Heater Hf-40kw

MOQ: 1
Price: 1800
Packaging Details: PLY WOODEN PACKAGE
Payment Terms: L/C,D/A,D/P,T/T
Detail Information
Product Description
Detail Information
Model NO.:
HF-40KW
Structure:
Vertical Type
Brand:
OURUIDA
Power:
40kw
Frequency:
30-80kHz
Working Application:
Heating, Forging, Quenching, Melting, Annealing
Length Of Cable:
5m+2m Flexible Connection
Work Power:
3*380V/415V/440V/480V 50-60Hz
The Range Of Operating Voltage:
340-430V AC
Input Current:
40A
Principle:
Induction Heating
Core:
IGBT
Style:
Induction Heating Machine
Transport Package:
Wooden Box
Specification:
CE, SGS, ISO
Trademark:
ORD
Origin:
China
HS Code:
8514400090
Production Capacity:
10, 000sets
Supply Ability:
1000SETS/MONTH
Highlight:

portable high frequency induction heater

,

handheld induction heater 40kw

,

IGBT induction heater HF-40kw

Product Description

IGBT Protable High Frequency Induction Heating equipment HF-40KW

IGBT portable Handheld High Frequency Induction Heater Hf-40kw

Advantage:

  • More than 21 years experience,stable and goods performance
  • CE certificated
  • Copperated with CHOW TAI FOOKS, Matsushita, Foxconn, Media, Gree and ZHIGAO Air conditioner.
  • Suitable for a large range, heating, quenching, forging, melting, solding and so on.
  • 2 Transformer ratios more options connect induction coil
  • Coaxial Connection Flexible, can handle the flexible to work the workpiece that normal coil can not get it.

Main characteristics:

  • IGBT module and Inverting technologies of third generation been used; Higher reliability and lower maintenance cost.
  • 100% Duty cycle, continuous working is allowed at maximum power output.
  • Display of heating power and heating current and oscillating frequency;
  • Simple to install, Installation can be done by unprofessional person very easily;
  • Light weight
  • Advantages of the model with timer: The power and the operating time of the heating period and the retain period can be preset respectively, to realize a simple heating curve, this model is suggested to use for batch production to improve the repeatability;
IGBT portable Handheld High Frequency Induction Heater Hf-40kw

Packing Photos:

IGBT portable Handheld High Frequency Induction Heater Hf-40kw
IGBT portable Handheld High Frequency Induction Heater Hf-40kw
IGBT portable Handheld High Frequency Induction Heater Hf-40kw
IGBT portable Handheld High Frequency Induction Heater Hf-40kw

Technical Specifications:

Type HF-40KW
Work Power 3*380v/415v/440v/480v 50-60hz
The range of operating voltage 340-430V AC
Output power 40KW
Input current 40A
Fluctuating frequency 30-80khz
Timing (Heat time,Retain time,Cool time) 1-99S
The flow rate of cooling water 0.15 Mpa 9L/Min
Water temperature protection point 40centidegree
Duty cycle 100% (40degree room temperature)
Weight Mainparts:32Kg+28KG
Size Main Parts:560*230*480mm
Transfromer Part: 460*265*440MM
Tags:

SGS High Frequency Induction Heating Machine

30Khz Hardening Equipment for Pipe

80Khz High Frequency Induction Heater Furnace
